CC36 SERIES
Description
CC36 SERIES

Ø 36mm × L 55mm / Shaft Ø 4 mm / P.C.D. Ø 23mm
DC 12V : 5.5W / 10W / 13W / 20W (2000~3800 rpm)
DC 24V : 8W / 12. / 18W / 26W (2400~4500 rpm)


Ask here to find the product that meets your needs
if you want more detailed specifications Or to purchase lot of products, please leave your message and specification. Or Email to us
Unit Price
$0
Number
ea

VIEW LIST

Detailed Information


Features



DC Coreless Motor Series CC02904N4 <12Volt>

RATEModel No.012005012010012013012020
Voltage(V)12121212
Current(mA)600120015002000
Power(W)5.510.013.020.0
Speed(rpm)1600230025003100
Torque(mN*m)30.040.050.060.0
ELECTRICALMaximum Output Power(W)8.715.022.033.0
Maximum Efficiency(%)65687375
No Load Speed(rpm)2000280030003800
No Load Current(mA)120150150200
Stall Torque(mN*m)170.0200.0270.0320.0
Torque Constant(mN*m/A)54.038.436.628.5
Back EMF Constant(mV/rpm)6.004.103.853.15
Termainal Resistance(Ω)3.802.201.601.10
Termainal Inductance(mH)0.050.030.020.02
MECHANICALMechanica Time Const(ms)4.34.93.94.4
Armature Inertia(g*㎠) 32.832.832.832.8
Shaft Diameter φ4φ4φ4φ4
Bearing TypeMetal BearingBall Bearing
Weight(g)270270270270
Maximum Armature Temperature120 ℃
Motor Operating Temperature Range-20 ~80℃


DC Coreless Motor Series CC02904N4 <24Volt>

RATEModel No.024008024012024018024026
Voltage(V)24242424
Current(mA)50080010001500
Power(W)8.012.018.026.0
Speed(rpm)1800240029003700
Torque(mN*m)40.050.060.070.0
ELECTRICALMaximum Output Power(W)12.020.028.043.0
Maximum Efficiency(%)67747678
No Load Speed(rpm)2400300036004500
No Load Current(mA)70708090
Stall Torque(mN*m)190.0250.0290.0360.0
Torque Constant(mN*m/A)90.973.561.250.0
Back EMF Constant(mV/rpm)11.56.805.003.50
Termainal Resistance(Ω)0.090.070.060.04
Termainal Inductance(mH)4.54.14.44.6
MECHANICALMechanica Time Const(ms)32.832.832.832.8
Armature Inertia(g*㎠) 10.610.610.610.6
Shaft Diameter φ4φ4φ4φ4
Bearing TypeMetal BearingBall Bearing
Weight(g)270270270270
Maximum Armature Temperature120 ℃
Motor Operating Temperature Range-20 ~80℃
